Epson EMP-X3 User Manual

64
Saving a User's Logo
You can record the image that is currently being projected as a user's logo.
PROCEDURE
A
Project the image you would like to use as the user’s
logo, and then display the configuration menu.
B
Select "Extended" from the configuration menu, and
then select "User’s Logo".
For details on this operation, refer to
"Using the Configuration
Menu
". sp.32
Check which buttons on the remote control or the control panel
you can use, and the operations they perform, in the guide at the
bottom of the screen.
When a user's logo is recorded, the previous user's logo
will be erased.
Using the remote control
Using the control panel
•If the "User’s Logo Protect" function of "Password
Protect" is set to "On", a message is displayed and the
user's logo can not be recorded. To record a user's logo,
set "User’s Logo Protect" to "Off" first. sp.28
•If keystone correction, E-Zoom and so on, have been
carried out, the function currently being performed is
cancelled when the "User’s Logo" menu is selected.

Epson EMP-X3 Specifications

General

Display resolution	1024 x 768 pixels
Number of colors	16.78 million colors
Vertical scan range	50 - 85 Hz
Horizontal scan range	15 - 92 kHz
Contrast ratio (typical)	400:1
Projector native resolution	XGA (1024x768)
Video in	Mini D-sub 15pin x 1
I/O ports	USB B x1, RCA x 1, Mini DIN, Mini D-sub 15pin
Audio input	RCA x 2
Aspect ratio	4:3
Dimensions (WxDxH)	327 x 246 x 86 mm
Power requirements	100 - 240V ±10%, 50 / 60Hz AC
Lamp type	UHE
Lamp power	170 W
Light source type	Lamp
Service life of light source	2000 h
Noise level	30 dB
Power consumption (typical)	240 W
Operating temperature (T-T)	5 - 35 °C
Market positioning	Home cinema

Weight and Dimensions

Weight	2600 g
