Epson EMP-X3 User Manual

65
Saving a User's Logo
C
When "Choose this image as the User's Logo?"
appears, select "Yes".
D
The image to be recorded and a selection marquee
box will be displayed. Move the marquee box to select
the part of the image to use.
E
When "Select this image?" appears, select "Yes".
F
Select the zoom rate from the Zoom rate setting
screen.
G
When "Save this image?" is displayed, select "Yes".
The image will then be saved. Once the image has been saved,
the message "Completed." will be displayed.
When you press the [Enter] button on either the remote
control or the projector's control panel, the image signal
will be displayed at their original resolution, so if a
signal with a resolution that is different from the panel
resolution of the projector is projected, or if a video
image is being projected, the display size will change.
Using the remote control
Using the control panel
User's logos can be saved at up to 400 × 300 dots in size.
•Saving the user's logo may take a few moments (about
15 seconds). Do not use the projector or any other
sources which are connected to the projector while the
user's logo is being saved, otherwise it may result in
errors in projector operation.
•Once a user's logo has been saved, the logo setting
cannot be returned to the factory default.

Epson EMP-X3 Specifications

General

Display resolution	1024 x 768 pixels
Number of colors	16.78 million colors
Vertical scan range	50 - 85 Hz
Horizontal scan range	15 - 92 kHz
Contrast ratio (typical)	400:1
Projector native resolution	XGA (1024x768)
Video in	Mini D-sub 15pin x 1
I/O ports	USB B x1, RCA x 1, Mini DIN, Mini D-sub 15pin
Audio input	RCA x 2
Aspect ratio	4:3
Dimensions (WxDxH)	327 x 246 x 86 mm
Power requirements	100 - 240V ±10%, 50 / 60Hz AC
Lamp type	UHE
Lamp power	170 W
Light source type	Lamp
Service life of light source	2000 h
Noise level	30 dB
Power consumption (typical)	240 W
Operating temperature (T-T)	5 - 35 °C
Market positioning	Home cinema

Weight and Dimensions

Weight	2600 g
