Displays the network connection status.
The printer is not connected to a wired (Ethernet) network or unset it.
The printer is connected to a wired (Ethernet) network.
The printer is not connected to a wireless (Wi-Fi) network.
The printer is searching for SSID, unset IP address, or having a problem with a wireless (Wi-Fi)
network.
The printer is connected to a wireless (Wi-Fi) network.
The number of bars indicates the signal strength of the connection. The more bars there are, the
stronger the connection.
The printer is not connected to a wireless (Wi-Fi) network in Wi-Fi Direct (Simple AP) mode.
The printer is connected to a wireless (Wi-Fi) network in Wi-Fi Direct (Simple AP) mode.
Select to display the Network Connection Settings screen. This is the shortcut for the following menu.
Settings > Network Settings > Wi-Fi Setup
❏ When the printer is not connected to the network yet.
Select the icon for the method you want to use to connect, and then select Start Setup on the next
screen to display the settings menu.
❏ When the printer is connected to the network already.
Displays the information of the network settings such as the printer's IP address.
Indicates that Quiet Mode is set for the printer. When this feature is enabled, the noise made by printer
operations is reduced, but print speed may slow down. However, noises may not be reduced depending
on the selected paper type and print quality.
Select to change the setting. This is the shortcut for the following menu.
Settings > Printer Settings > Quiet Mode
Closes the output tray.
Icons common to each screen
Displays the home screen from any screen. On the home screen, indicates this is the home screen.
Displays the Help screen. You can view the operating instructions or the solutions to problems.
User's Guide
Printer Basics
21
