Epson FX-2190 Service Manual

EPSON FX-890/2190 Revision B
Operating Principles Overview 51
Note “*1”: Each value indicated here is only the average of measured values of samples
(sample size n = 3), that is, it is not a typical value or guaranteed value.
“*2” : Each value does not include the current flowing in the capacitor of the EMI filter
circuit.
OUTPUT SPECIFICATIONS
Note “*1”: Neither Output 1 nor Output 2 includes the spike voltage component.
“*2” : The output current during power supply startup must be not greater than the value
specified above.
“*3” : The values for ripple and spike voltage indicated above, which are the values with a
rated resistance load, are only for reference. (Ambient temperature: 25
°C)
For measurement, connect a KMF50V470µF electrolytic capacitor and 0.1 µF film
capacitor to the output 1 terminal, and a KME16V47
µF electrolytic capacitor and
0.1
µF film capacitor to the output 2 terminal.
PROTECTIVE FUNCTIONS
Special output holding
time
(The period from the
time when output 1 has
dropped below 26 V to
the time when output 2
drops below the output
voltage lower limit)
120 ms or more
(Input: 85 V, 60 Hz) (Input: 187 V, 50 Hz) (Input: 85 V, 60 Hz)
(Output: At output 1 of no-load and output 2 of rated load)
Table 2-5. Output Specifications
Item Output 1 Output 2
Rated output voltage +42 V +5 V
Output voltage fluctuation
*1
40.0 ~ 44.0 V 4.75 ~ 5.25 V
Rated output current 0.8 A 0.7 A
Output current at startup
*2
0 A 0.7 A
Output current range 0~2.8 A 0~0.7 A
Ripple voltage
*3
----- 100 mVpp Typ.
Spike voltage
*3
1500 mVpp Typ. 300 mVpp Typ.
Table 2-4. Input Specifications
Power Supply Unit
Name
C524 PSB
(100-120V Spec)
C524 PSE
(220-240V Spec)
C524 PSH
(100-240V Spec)
Table 2-6. Protective Functions
Item Output 1 Output 2
Overcurrent protection (OCP) Dropping + cutoff Cutoff
OCP reset method
Turning power off
once and on again
Turning power off
once and on again
Load short-circuit current 0 A 0 A
Overvoltage protection (OVP) Cutoff type Cutoff type
OVP preset voltage 45 ~ 58 V 6 ~ 9 V

Epson FX-2190 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Color	No
Character pitch	10 cpi
Maximum resolution	240 x 144 DPI
Maximum printing width (columns)	136
Print technology	Dot matrix
Dimensions (WxDxH)	589 x 360 x 157 mm
Standard interfaces	Parallel, USB 1.1
Optional connectivity	Ethernet
Country of origin	Indonesia
Sound pressure level (printing)	55 dB
Mean time between failures (MTBF)	20000 h
Sustainability certificates	ENERGY STAR
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Power consumption (typical)	53 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2040 mm
Quantity per pallet	14 pc(s)
Quantity per pallet (UK)	21 pc(s)
Quantity per pallet layer	2 pc(s)
Quantity per pallet layer (UK)	3 pc(s)
Package depth	700 mm
Package width	460 mm
Package height	270 mm
Package weight	11740 g
Quantity per pack	1 pc(s)
