Epson RC700-A Original Instructions

Installation 2. Installation
RC700 Series Rev.3 13
Max. Reaction torque on
the horizontal plate (N·m)
M12
The plate for the Manipulator mounting face should be 30 mm thick or more and made of
steel to reduce vibration. The surface roughness of the steel plate should be 25 μm or less.
N2 Series
N2-A450S*
Max. Reaction torque on
the horizontal plate (N·m)
200
Max. Horizontal reaction
force (N)
300
Max. Vertical reaction
force (N)
300
Threaded holes for
Mounting screw
1,600
Max. Reaction torque on
the horizontal plate (N·m)
M6
The plate for the Manipulator mounting face should be 20 mm thick or more and made of
steel to reduce vibration. The surface roughness of the steel plate should be 25 μm or less.
N6 Series
N6-A1000**
N6-A850**R
Max. Reaction torque on
the horizontal plate (N·m)
800 800
Max. Horizontal reaction
force (N)
1,900
1600
Max. Vertical reaction
force (N)
1,100
1100
Threaded holes for
Mounting screw
3,200
5100
Max. Reaction torque on
the horizontal plate (N·m)
M12 M12
The plate for the Manipulator mounting face should be 30 mm thick or more and made of
steel to reduce vibration. The surface roughness of the steel plate should be 25 μm or less.
