21
Before Use
Status Display Area Icons
The following explains the meaning of each icon.
[Pause] Pauses or resumes printing.
[Cancel] Cancels printing.
[Clean] Moves the carriage to the cleaning position (maintenance position).
[Flush] Performs flushing.
[Left] Moves the carriage to the left.
[Right] Moves the carriage to the right.
[Back] Moves the gantry to the back.
[Forward] Moves the gantry to the front.
[X Reset]
Moves the carriage to the X reset position (the leftmost position in the
carriage's range of motion).
[Y Reset]
Moves the gantry to the Y reset position (the frontmost position in the
gantry's range of motion).
[Move Back] Moves the gantry to the rearmost position.
Display Meaning
Connected to the printer.
Not connected to the printer.
Icon Name Function
