Printing the Color Layer and Varnish Layer Separately
<Workflow>
1
Operations in Epson Edge Print
2
Operations from the UV Flatbed Controller
Operations in Epson Edge Print
1
Click (Add) on the job toolbar to add print data to the job list. You can also drag
and drop the print data file onto the job list.
A thumbnail and data name of the added print data is displayed in the job list, and the following three lay-
ers are displayed below the data name.
• [First Layer [White] (No Data)]
• [Second Layer [Color]]
• [Third Layer [Varnish] (No Data)]
2
Select the job you added in the job list.
The print image is displayed in the preview area.
1-1 Print the data without using multi-layer print settings. (Output a color layer of the PRN file.)
1-2 Create and print a layer-only job for varnish printing with the same print data. (Output a varnish
layer of the PRN file.)
Print the color layer and then the varnish layer in that order on the same media.
To Next Page
