47
Using the Functions of the UV Flatbed Controller
Test Printing (Nozzle Check)
The size of the check pattern is 245 mm (H) and 195 mm (V).
1
Select [Adjust] - [Nozzle Check] on the screen.
2
Adjust the head height, and then set the print start positions (X and Y positions).
N"Adjusting the Height of the Print Head" on page 45
3
Select [Print] to print a check pattern.
To Next Page
