Slider
A Slider
Mount the chip unit included with the ink pack.
U “Refilling ink” on page 73
B Ink inlet cover
Open this when refilling the ink tank with ink.
C Chip unit
The IC chip is a built-in unit.
It is included with the ink pack.
Roll paper adapter
Use the supplied roll paper adapter when loading roll
paper onto the printer.
U “Loading Roll Paper” on page 25
A Adapter lock lever
Lift to unlock, lower to lock. Unlock when attaching
roll paper to the adapter, lock once the roll is
attached.
B Size lever
Position according to the size of the roll core.
SC-F6300 Series User's Guide
Introduction
9
