Specifying the 2D symbol data

See the following description to specify the 2D symbol data.

PDF417/MicroPDF417

•Calculated automatically when the digit number and the line number are 0.

•To specify other number than 0, make sure the multiplication of the digit number and the line

number is under 928.

QRCode

•It is changed automatically to the appropriate version.

Micro QRCode

•The size is automatically determined.

MaxiCode

•Specify the special character as the following format.

DataMatrix

•When data are '{', if the following does not apply to the data immediately after, an error occurs.

GS1 DataBar Stacked /GS1 DataBar Stacked Omnidirectional

•Do not specify the application identifier ‘01’ for the head of the data.

•A check digit need not to be attached to the data.

•When printing a 2D symbol with a composite symbol, delimit the data that specify a composite

symbol and 2D symbol with "\|" or "|\". Specify the data in order of a composite symbol and 2D

symbol.

Control Character Hexadecimal

SHIFT 0x7B, 0x53

CODE B 0x7B, 0x42

CODE C 0x7B, 0x43

FNC1 0x7B, 0x31

FNC2 0x7B, 0x32

FNC3 0x7B, 0x33

FNC4 0x7B, 0x34

Control Character ASCII

FNC1 {1

'{' {{
