Epson TM-C7500 Series User Manual

96
Position adjustment
Adjusts the print start position or cut position.
Item Description
Justify Print start position
adjustment 
(Vertical direction)
Adjusts the print start position in the vertical direction.
Click [Start adjustment...] to adjust the position.
Print start position
adjustment 
(Horizontal direction)
Adjusts the print start position in the horizontal direction.
Click [Start adjustment...] to adjust the position.
Cut position adjustment Adjusts the cut position.
Click [Start adjustment...] to adjust the position.

Epson TM-C7500 Series Specifications

General

Resolution	600 x 1200 dpi
Colours	Cyan, Magenta, Yellow, Black
Power Supply	Internal
Print Speed	Up to 300 mm/sec
Media Width	2" (50 mm) - 4.25" (108 mm)
Interface	USB, Ethernet
Weight	Approximately 37 kg
Print Width	4.09" (104 mm)
Media Types	Roll
Supply Voltage	AC 100-240V, 50/60 Hz
Media Thickness	0.08 to 0.2 mm
