Epson TM-C7500 Series User Manual

24
Dot substitution
The dot substitution is a function that performs complementary printing using the nearby nozzles
when nozzles are clogged.
The maximum number of clogged nozzles that can be automatically supplemented is 16. However,
supplementation cannot be performed adequately in the case of clogging of an adjacent nozzle.
Note
that in the case of more than 16 clogged nozzles, supplementation for 16 nozzles will be
implemented. After that, printing can continue.
This function does not become enabled even when setting the dot substitution to enable if the Nozzle
Ver ification Technology is disabled.
Settings
It can be set from the setting menu of this product and PrinterSetting.
The factory setting is "On".
See
"Setting panel switch" on page 82 or "PrinterSetting" on page 89
 This function does not completely remedy falls in print quality, barcode quality and so forth.
 This system carries out supplementation according to nozzle dropout information known at
the start of printing, and therefore is not able to supplement nozzle dropout that occurs
during printing.

Epson TM-C7500 Series Specifications

General

Resolution	600 x 1200 dpi
Colours	Cyan, Magenta, Yellow, Black
Power Supply	Internal
Print Speed	Up to 300 mm/sec
Media Width	2" (50 mm) - 4.25" (108 mm)
Interface	USB, Ethernet
Weight	Approximately 37 kg
Print Width	4.09" (104 mm)
Media Types	Roll
Supply Voltage	AC 100-240V, 50/60 Hz
Media Thickness	0.08 to 0.2 mm
