Epson TM-C7500 Series User Manual

63
Chapter 2 Setup
2
How to eject paper for paper replacement
Discharge the paper with the following steps.
1
Turn on the product.
2
Cut the paper, using the Cut button.
3
Press the Back Feed button for 1 second or longer.
4
Open the paper set cover.
5
Open the paper guide's two paper hold levers, and remove the paper.
In the case of fanfold paper, that completes paper ejection.
6
In the case of roll paper, open the roll paper cover and take the flange off.
7
While holding the release lever of the roll paper flange, pull out the roll
paper flange. Then, pull the roll paper out.
Paper Hold

Epson TM-C7500 Series Specifications

General

Resolution	600 x 1200 dpi
Colours	Cyan, Magenta, Yellow, Black
Power Supply	Internal
Print Speed	Up to 300 mm/sec
Media Width	2" (50 mm) - 4.25" (108 mm)
Interface	USB, Ethernet
Weight	Approximately 37 kg
Print Width	4.09" (104 mm)
Media Types	Roll
Supply Voltage	AC 100-240V, 50/60 Hz
Media Thickness	0.08 to 0.2 mm
