Epson TM-C7500 Series User Manual

62
Setting the Fanfold Paper
Set the fanfold paper by following the steps below.
1
Turn on the product.
2
Open the paper set cover.
3
Set the fanfold paper referring to Step 8 to 12 in " Setting the Roll Paper".
4
Close the paper set cover.
5
Place the fanfold paper straight 15 mm or more away from the rear side of
the product. Also, for the paper width direction, match it to the standard
marking on the rear side of the product.
6
Press the Pause button.
15 mm { }
0.59”

Epson TM-C7500 Series Specifications

General

Resolution	600 x 1200 dpi
Colours	Cyan, Magenta, Yellow, Black
Power Supply	Internal
Print Speed	Up to 300 mm/sec
Media Width	2" (50 mm) - 4.25" (108 mm)
Interface	USB, Ethernet
Weight	Approximately 37 kg
Print Width	4.09" (104 mm)
Media Types	Roll
Supply Voltage	AC 100-240V, 50/60 Hz
Media Thickness	0.08 to 0.2 mm
