Epson TM-C7500 Series User Manual

48
REPLACE MB
When there is almost no space that can be used in the Maintenance box, the Ink LED is lit,
[REPLACE MB] is displayed on LCD and the product changes to offline.
Change to a Maintenance box with enough space using the following steps.
1
Check that the INK LED on the printer is lit up, and check that the
maintenance box displays "REPLACE MAINT B" on the LCD.
2
Open the maintenance box cover towards you.
3
Pull out the used maintenance box towards you.

Epson TM-C7500 Series Specifications

General

Resolution	600 x 1200 dpi
Colours	Cyan, Magenta, Yellow, Black
Power Supply	Internal
Print Speed	Up to 300 mm/sec
Media Width	2" (50 mm) - 4.25" (108 mm)
Interface	USB, Ethernet
Weight	Approximately 37 kg
Print Width	4.09" (104 mm)
Media Types	Roll
Supply Voltage	AC 100-240V, 50/60 Hz
Media Thickness	0.08 to 0.2 mm
