Epson TM-T81 Technical & Specifications Manual

Confidential
EPSON
TITLE
SHEET
REVISION
NO
SHEETNEXT
A
App.6 App.5
TM-T81
Specification
(STANDARD)
APPENDIX C: RECOVERY FROM THE AUTO CUTTER ERROR
• If a foreign object such as a push pin or paper clip drops in the auto cutter and causes the auto
cutter to lock up, the printer enters an error state and begins the recovery operation automatically.
(The error LED flashes continuously, but it is possible for the error to be corrected automatically.)
If the problem is not serious, the auto cutter returns to its normal position without any intervention
by the user.
If the auto cutter does not return to its normal position by itself, follow the steps below to correct
the problem:
1) Pull the cutter cover toward you and remove it so that you can rotate the cutter motor
knob.
2) Rotate the cutter motor knob to the direction indicated by an arrow on the autocutter unit.
3) Following the instructions on the caution label, rotate the knob until the indicator ▼
appears in the hole.
• If the motor knob cannot be rotated, rotate it in the reverse direction to loosen it; then send the
DLE ENQ n command. Next, check the ERROR LED. If the ERROR LED is not off, repeat the
same procedure and confirm that the ERROR LED is off. When the ERROR LED is off, the auto
cutter blade has returned to its normal position and the roll paper cover can be opened. Open
the roll paper cover, remove the jammed paper, and reinstall the roll paper. Then close the roll
paper cover.

Epson TM-T81 Specifications

General

Print Method	Thermal line printing
Autocutter	Yes
Interface	USB, Ethernet
Dimensions	140 mm (W) x 199 mm (D) x 146 mm (H)
Power Supply	AC 100 V - 240 V, 50 Hz - 60 Hz
Paper Width	79.5 ±0.5 mm
