Rev. B Parts List Appendix-5
TM-U220 Type A Service Manual
Confidential
1105 Take-up transmission gear Gear,take-up transmission 1 No
1106 Middle take-up gear Gear,take-up middle 1 No
1107 Cutter support frame sub assembly Frame cutter support sub assembly 1 No
1108 Cutter support frame Frame,cutter support 1 No
1109 Cutter support shaft Shaft,cutter support 1 No
1110 Paper take-up gear assembly Paper take-up gear assembly 1 No
1111 Take-up flapper spring Take-up flapper spring 1 No
1112 Take-up transmission shaft Shaft,take-up transmission 1 No
1114 Rotation cutter frame assembly Frame rotation cutter assembly 1 No
1115 Cutter rotation frame sub assembly Frame rotation cutter sub assembly 1 No
1116 Cutter rotation frame Frame,rotation cutter 1 No
1117 Cutter paper guide Paper guide,cutter 1 No
1118 Rotation frame spacer Spacer,frame rotation 1 No
1119 Roll paper guide spring Spring,roll paper guide 1 No
1120 Roll paper guide plate Plate,roll paper guide 1 No
1121 Manufacturer’s plate Manufacture’s plate 1 No
1122 Roll paper cover Cover,roll paper 1 No
1123 Open lever Lever,open 1 No
1124 Platen rotation frame 2 unit Frame platen rotation,2 unit 1 No
1125 Platen rotation frame 2 Frame,platen rotation,2 1 No
1126 Nut Nut 1 Yes
1127 E-ring 2.3 E-ring 2.3 1 No
1128 CBS-TITE, 3X5, F/ZN C.B.S- TITE,3X5,F/ZN 2 No
1129 Cutter rotation plate Plate,rotation cutter 1 No
E01 E-ring 3 E-ring,3 9 Yes
E02 E-ring 2.3 E-ring,2.3 5 Yes
E03 E-ring 4 E-ring,4 2 Yes
E04 E-ring 3 E-ring,3 2 Yes
S01 CPS(O) screw, 3X6 C.P.S.(O) Screw,3X6 8 Yes
S02 CPS-TITE, 3X5,F/ZN C.P.SITITE,3X5,F/ZN 8 Yes
S03 CBS screw, 3X6 C.B.S. Screw,3X6 12 Yes
S04 CB screw, 2X2.5, F/ZN C.B. Screw,2X2.5,F/ZN 1 Yes
S05 CBP-TITE screw, 3X8, F/ZN C.B.P-TITE Screw,3X8,F/ZN 5 Yes
S06 Screw (P tight) SCREW(P tight) 1 Yes
S07 CBP-TITE, 3X10, F/ZN C.B.P-TITE,3X10,F/ZN 2 Yes
S08 CBP-TITE screw, 3X6, F/ZN C.B.P-TITE Screw,3X6,F/ZN 3 Yes
S09 CBS-TITE, 3X4, F/ZN C.B.S-TITE,3X4,F/ZN 5 Yes
Table A-1 Parts List by Reference Number
Ref. # Service Manual Name Parts Price List Name Qty.
Supplied as a part?
