Appendix-4 Parts List Rev. B
Confidential
1056 Platen release spring Spring,platen release 1 No
1057 Gear plate D sub assembly Plate,gear,D sub assembly 1 No
1058 Paper feed reduction gear 2 Gear,paper feed reduction,2 1 No
1059 Paper feed reduction shaft 2 Shaft,paper feed reduction,2 1 No
1060 Middle paper feed shaft Shaft,paper feed middle 1 No
1061 Bottom holding plate bm Holding plate,bm,bottom 1 No
1063 Paper feed gear Gear, paper feed 1 No
1069 S Push N, 3, F / Zn S Push N,3,F / Zn 1 No
1071 Cutter cover sub assembly Cover, cutter sub assembly 1 No
1072 Drive gear sub assembly Gear, drive sub assembly 1 No
1073 Insulator plate assembly Plate,insulator assembly 1 No
1074 Platen Platen 1 No
1075 Paper feed roller Paper feed roller 1 No
1076 Platen assembly 1 Platen assembly,1 1 No
1077 Belt tension plate assembly Plate belt tension assembly 1 No
1078 Carriage Carriage 1 No
1079 Base frame sub unit Frame,base sub unit 1 No
1080 Micro switch Micro switch 1 No
1081 Ferrite core Ferrite core 1 No
1084 Roll paper cover BA Cover,roll paper,BA 1 No
1085 Bottom frame assembly Frame,bottom assembly 1 No
1086 Belt tension plate sub assembly Plate belt tension sub assembly 1 No
1088 Ribbon take-up spring Spring,ribbon take-up 1 No
1089 FFC cover tape Tape,FFC cover 1 No
1090 AC lead wire set Lead wire set,AC 1 No
1091 Micro switch Micro switch 1 No
1092 Hook spring C Spring,hook,C 1 No
1093 Paper feed reduction gear 1 Gear,paper feed reduction,1 1 No
1094 Gear drive Gear drive 1 No
1095 IC cover IC Cover 1 No
1096 NE lead wire set Lead wire set, NE 1 No
1097 Ribbon release spring Spring,ribbon release 1 No
1099 Ribbon cassette Ribbon cassette 1 No
1100 CBS-TITE screw, 3X12, F/ZN C.B.S-TITE SCREW,3X12,F/ZN 2 No
1101 CBB-TITE screw, 2X8, F/ZN C.B.B-TITE SCREW,2X8,F/ZN 1 No
1102 Paper hold roller shaft Shaft, paper hold roller 1 No
1104 Cutter rotation spring Spring,rotation cutter 1 No
Table A-1 Parts List by Reference Number
Ref. # Service Manual Name Parts Price List Name Qty.
Supplied as a part?
