Rev. B Parts List Appendix-3
TM-U220 Type A Service Manual
Confidential
1014 Paper hold spring Spring,paper hold 1 No
1015 Paper hold roller Roller,paper hold 2 No
1016 Fixed blade spring Spring,fixed blade 1 No
1017 Fixed blade holder Holder,fixed blade 1 No
1018 Cover open plate Plate,cover open 1 No
1022 Ribbon frame spring Spring,ribbon frame 1 No
1023 Ribbon frame shaft L Shaft,ribbon frame,L 1 No
1024 Ribbon frame Frame,ribbon 1 No
1025 Carriage sub assembly Carriage sub assembly 1 No
1026 Carriage guide plate sub assembly Plate,carriage guide sub assembly 1 No
1027 Carriage shaft Shaft,carriage 1 No
1028 Carriage motor plate sub assembly Plate,carriage motor sub assembly 1 No
1029 Belt tension pulley Pulley,belt tension 1 No
1030 Carriage guide plate Plate,carriage guide 1 No
1032 Belt pulley shaft Shaft,belt pulley 1 No
1033 Belt tension plate Plate belt tension 1 No
1034 Carriage motor sub assembly Motor,carriage sub assembly 1 No
1035 Ribbon take-up gear shaft Shaft,ribbon take-up gear 1 No
1036 Middle ribbon gear shaft Shaft,ribbon middle gear 1 No
1037 Roll paper guide Guide,roll paper 1 No
1038 Roll paper guide unit Guide,roll paper unit 1 No
1039 Micro switch Micro switch 1 No
1040 Detector adjustment screw Detector adjustment screw 1 No
1041 NE detector assembly N.E.detector assembly 1 No
1042 NE detector holder Holder,N.E.detector 1 No
1043 NE detector lever Lever,N.E.detector 1 No
1044 Roll paper holder assembly Holder roll paper assembly 1 No
1045 Paper guide roller Roller,paper guide 1 No
1046 Paper feed motor sub assembly Motor paper feed sub assembly 1 No
1047 PF lead wire set Lead wire set,PF 1 No
1048 Paper feed reduction shaft 1 Shaft,paper feed reduction,1 1 No
1049 Platen fixing shaft R Shaft,platen fix,R 1 No
1050 Rotation frame spacer Spacer,frame rotation 1 No
1052 Cover open lever Lever,cover open 1 No
1053 Platen frame Frame,platen 1 No
1054 Platen shaft Shaft,platen 1 No
1055 Platen release plate Plate,platen release 1 No
Table A-1 Parts List by Reference Number
Ref. # Service Manual Name Parts Price List Name Qty.
Supplied as a part?
