Rev. B Product Overview 1-5
TM-U220 Type A Service Manual
Confidential
4. Insert the roll paper.
Note:
Note the direction that the paper comes off the roll, as shown above.
When using two-ply paper, be sure that the top and bottom sheets are aligned at the paper exit. Do not
allow paper to be loaded as shown below.
5. If you are not using the take-up flange, pull out a small amount of roll paper and close the
roll paper cover. Then, tear off the paper with the manual cutter. You can skip steps 6
through 11.
6. When using 2-ply roll paper, pull out the roll paper to the bottom front of the printer, as
shown below.
To Next Page
