A
Document cover Blocks external light while scanning.
B
Scanner glass Place the originals.
C
SD card slot Insert a memory card.
D
External interface USB port Connects an external storage device or a PictBridge capable device.
A
AC inlet Connects the power cord.
B
Rear cover Remove when removing jammed paper.
C
USB port Connects a USB cable to connect with a computer.
Part Names and Functions
>
Part Names and Functions
20
