EQUIL MTM-I - Removing the Infusion Set

Equil
TM
Insulin Patch Pump System
51
5
Figure 57
6
If the needle remains in the
inserter, place the protective sleeve back
onto the needle hub. Firmly push the top of
the inserter to eject the needle hub
(Figure 58) and dispose of properly.
Figure 58
7.2 Removing the Infusion Set
Figure 59
Dispose of the insertion needle
properly in a medical sharps container.
Note
Release the inserter from the pump base
by pressing the button on the lower end of
the cannula inserter as shown in Figure 57. If
the inserted needle or needle base remains
in the pump base, carefully remove it from
the infusion site. Place the protective sleeve
back onto the cannula assembly.
Peel away one end of the tape from
the skin as shown in Figure 59 and
continue until the entire infusion set has
been removed.
