EQUIL MTM-I - Disassembling the Reservoir

Equil
TM
Insulin Patch Pump System
55
Figure 67
Be sure that the battery is inserted in the
orientation shown in Figure 68.
Figure 68
7.5 Disassembling the Reservoir
Holding the pump and reservoir in the
orientation shown in Figure 69, bend the
assembly along the seam line as shown
until the reservoir separates from the
pump. Be sure to recharge the battery
immediately to make sure that a fresh
battery is always installed with a new
reservoir. Dispose of the used reservoir in a
medical sharps container.
Figure 69
Pay close attention to the orientation
of the pump during disassembly.
Incorrect disassembly may cause
damage.
Note
