EQUIL MTM-I - Page 76

Equil
TM
Insulin Patch Pump System
71
10.3.1 Fingertip Testing
Adjust the penetration depth of the
lancing device to reduce the level of
discomfort.
1
Remove the lancing device cap. Insert
the lancet into the lancet holder until it
comes to a complete stop as indicated in
Figure 86.
Figure 86
2
Twist off the safety cap from the lancet,
(Figure 87) and save the safety cap for
lancet disposal.
.
Figure 87
3
Carefully install the lancing device cap
onto the lancing device, avoid touching the
lancet needle tip (Figure 88).
Figure 88
4
5
4
5
