8 MEMORY MANAGEMENT
0460 949 474
- 36 -
© ESAB AB 2021
WELD DATA MEMORY
5 - (SAW)
SAW: CA: FE SOLID: 3.0 mm
30.0 V: 450 A: 50 cm/min
NO YES
DELETE WELD DATA NR. 5?
8.5 Copy
To copy the content of a weld data set to a new memory position, proceed as follows:
Press 2ND FUNCT.
WELD DATA MEMORY
5 - (SAW)
SAW: CA: FE SOLID: 3.0 mm
30.0 V: 450 A: 50 cm/min
STORE RECALL DELETE 2ND FUNCT QUIT
Select the memory position you want to copy and press COPY.
WELD DATA MEMORY
5 - (SAW)
SAW: CA: FE SOLID: 3.0 mm
30.0 V: 450 A: 50 cm/min
COPY RENAME EDIT 2ND FUNCT QUIT
We are now going to copy the content of memory position 5 to position 50.
Select memory position 1 and scroll through using one of the settings knobs to the selected
memory position; in this case, position 50. Press YES.
