ESAB A2 PEK - 3 SUBMERGED ARC WELDING; 3.1 Submerged Arc Welding Settings

3 SUBMERGED ARC WELDING
0460 949 474
- 17 -
© ESAB AB 2021
3 SUBMERGED ARC WELDING
MAIN MENU » PROCESS
During Submerged Arc Welding (SAW), an arc melts a continuously supplied wire. The weld
pool is protected by flux.
Aristo® 1000: When the SAW process is selected, choose METHOD with the positioning
knob and press ENTER. Choose AC or DC.
SAW
PROCESS
METHOD
REGULATION TYPE
WIRE TYPE
WIRE DIMENSION
CONFIGURATION►
TOOLS►
SAW
AC
CC
Fe SOLID
0.8 mm
SET MEASURE MEMORY FAST MODE
Aristo® 1000: When the SAW process is selected, you can choose between three control
methods by marking REGULATION TYPE using the positioning knob and pressing ENTER.
Choose between constant welding current CA or constant wire feed CW or constant current
CC.
LAF/TAF: When the SAW process is selected, you can choose between three control
methods by marking REGULATION TYPE using the positioning knob and pressing ENTER.
Choose between constant welding current CA or constant wire feed CW.
See explanations in "CA, constant amperage", "CW, constant wire feed" and "CC, constant
current".
If ICE wire feed is selected, see "ICE wire feed", page53, only regulation type CW can be
selected.
3.1 Settings for submerged arc welding
Settings Setting range In steps of Value after
resetting
Arc voltage
1)
For Aristo® 1000 14 -50 V 0.1 V (1V) 30 V
For LAF/TAF 8 - 60 V 0.1 V (1V) 30 V
Welding current
1)
(CA)
0 - 3200 A 1 A 400 A
Wire feed speed
1)
(CW)
0 - 2500 cm/min 1 cm/min 100 cm/min
Constant current
1) 3)
(CC)
0 - 3200 A 1 A 500 A
ICE wire feed speed
1)
0 - 200% 1% 100%
ICE wire start delay
1)
0 - 99,0 s 0,1 s 2,5 s
Travel speed * 0 - 200 cm/min 1 cm/min 30 cm/min
Welding direction ▲-■ - ■
AC frequency
3)
10 - 100 Hz 1 50 Hz
