ESAB A2 PEK - ICE Wire Feed

9 CONFIGURATION MENU
0460 949 474
- 53 -
© ESAB AB 2021
PARALLEL POWERSOURCES
PARALLEL POWERSOURCES ON
Parallel couple ID
Connect with slave

1
- -
QUIT
CONNECT
When the master and slave power sources are connected, the text Connected is presented.
9.3.9 ICE wire feed
NOTE!
ICE option is only available with purchasing of ICE license.
The option ICE WIRE FEEDON can be selected in the machine configuration menu. If ICE
wire feed is selected, the option ICE WIRE FEED AXIS appears.
MACHINE CONFIGURATION
PRODUCT CODE
WIRE FEED AXIS
ICE WIRE FEED AXIS►
TRAVEL AXIS►
TANDEM
ICE WIRE FEED
NODE ID SETTINGS►
FREE 2 AXIS



OFF
ON
QUIT
The ICE wire feed axis settings must be identical to the wire feed axis.
ICE WIRE FEED AXIS
MOTOR
GEAR 1►
└ N 1
└ N 2
GEAR 2►
└ N 1
└ N 2
FEED ROLLER DIAM
ENCODER PULSES
LOW MANUAL SPEED
5035 38 RPM
ON
156
1
ON
1
1
49 mm
32 ppr
150 cm/min
QUIT
Motor is selected from a dropdown list with the following options:
