ESAB A2 PEK - 8.7 Edit Weld Data

8 MEMORY MANAGEMENT
0460 949 474
- 37 -
© ESAB AB 2021
WELD DATA MEMORY
1 -
5 - (SAW)



COPY
DATA SET 5 TO POSITION: 50
NO YES
Weld data number 5 has now been copied to memory position 50.
8.6 Name
To give a stored weld data set its own name, proceed as follows:
Press 2ND FUNCT. Select the memory position you want to rename and press RENAME.
WELD DATA MEMORY
5 - (SAW)
50 -


SAW: CA: FE SOLID: 3.0 mm
30.0 V: 450 A: 50 cm/min
COPY RENAME EDIT 2ND FUNCT QUIT
Here you have access to a keyboard that is used as follows:
• Position the cursor on the desired keyboard character using the arrows and the
positioning knob. Press DONE. Enter a complete text string with a maximum of 40
characters in this way.
• Press DONE to store. The alternative you have named can now be seen in the list.
KEYBOARD
A B C D E F G H
I J K L M N O P
Q R S T U V W X Y Z
0 1 2 3 4 5 6 7 8 9
SPACE CAPS
0 (MAX 40)
DELETE SYMBOL DONE
8.7 Edit
To edit the content of a weld data set, proceed as follows:
Press 2ND FUNCT. Select the memory position you want to edit and then press EDIT.
