ESAB A2 PEK - Quality Data Log to File; Soft Key Configuration

9 CONFIGURATION MENU
0460 949 474
- 41 -
© ESAB AB 2021
FAST MODE SOFT KEYS
SOFT KEY NUMBER
ASSOCIATED WELD DATA



1
5
SAW: CA: FE SOLID: 0.8 mm
20.0 V: 500 A: 0 cm/min
STORE DELETE QUIT
The keys are numbered 1-4 from left to right. Select the desired key by giving its number
using the setting knobs.
Then scroll to the next row ASSOCIATED WELD DATA. Here you can browse through the
weld data sets that are stored in the weld data memory. Selected the desired weld data
number using the setting knobs. Press STORE to save. To delete the stored set, press
DELETE.
9.2.2 Quality data log to file
Activate QUALITY DATA LOG TO FILE menu by selecting ON.
GENERAL CONFIGURATION
FAST MODE SOFT BUTTONS
QUALITY DATA LOG TO FILE
SOFT KEYS SETUP►
AUTO SAVE MODE
UNIT OF LENGTH
1
ON

OFF
METRIC
QUIT
Read more about settings for the quality function in section "Quality functions".
9.2.3 Soft key configuration
For Submerged Arc Welding (SAW) and for Gas Metal Arc Welding (GMAW) welding, the
user has the possibility of setting the function of these keys by selecting from a list of set
options. There are eight soft keys that can be allocated a function.
It is possible to choose between the following options:
• None
• Gas / Flux
• Set values
Set reference values are displayed instead of the measured values in the
measurements menu.
• Relay 2
Sets relay output no.2 on the motor circuit board, which can be used for any function by
the customer.
• Direction
• Remote I/O
Used when you want to control PEK and a welding power source via an external I/O
unit.
