ESAB A2 PEK - Cold Wire Axis (ICE); Travel Axis; External Axis

9 CONFIGURATION MENU
0460 949 474
- 46 -
© ESAB AB 2021
9.3.3 Cold wire axis (ICE)
FREE 2 AXIS FREE 3 AXIS
Motor VEC 4000 VEC 4000
Gear 1 156:1 156:1
Gear 2 1:1 1:1
Diameter feed rollers 49 mm 49 mm
Pulse sensor 32 ppr 32 ppr
Low manual speed 150 cm/min 150 cm/min
High manual speed 300 cm/min 300 cm/min
9.3.4 Travel axis
The travel motor is set automatically according to the tables below.
A2TFJ1 A2TGJ1 A6TFF1 MTW600
Motor 4030-350 4030-350 FHP258 FHP258
Gear 1 375:10 375:10 24:1 75:2
Gear 2 51:1 51:1 51:1 51:1
Wheel diameter 158 mm 158 mm 180 mm 158 mm
Pulse sensor 60 ppr 60 ppr 28 ppr 60 ppr
High manual speed 200 cm/min 200 cm/min 200 cm/min 200 cm/min
FREE 2 AXIS FREE 3 AXIS N7500I Motor Control
Motor VEC 4000 VEC 4000 VEC 4000 VEC 4000
Gear 1 312:1 312:1 75:2 312:1
Gear 2 1:1 1:1 51:1 1:1
Wheel diameter 65 mm 65 mm 158mm 65mm
Pulse sensor 32 ppr 32 ppr 60ppr 32ppr
High manual
speed
200 cm/min 200 cm/min 200cm/min 200cm/min
9.3.5 External axis
When connecting an external roller bed, positioner or linear axis, FREE 3 AXIS must be
selected.
When FREE 3 AXIS is selected, the motor is automatically set according to the tables below.
Roller bed Linear Positioner
Gear 1 560:1 560:1 560:1
Gear 2 111:22 111:22 111:22
Gear 3 1:1 1:1 1:1
Wheel diameter 160 mm 160 mm 160 mm
Pulse sensor 30 ppr 30 ppr 30 ppr
High manual speed 200 cm/min 200 cm/min 200 cm/min
Frequency ratio 85:50 85:50 85:50
Motor 2000 rpm 2000 rpm 2000 rpm
