ESAB A2 PEK - 10.2 Data Transfer and File Management

10 TOOLS
0460 949 474
- 63 -
© ESAB AB 2021
 8411,
sub-
code 1
 Travel speed motor error
There are no pulses from the motor pulse transducer.
1. Check the motor cables. Replace the pulse transducer.
10.2 Export/Import
MAIN MENU » TOOLS » EXPORT / IMPORT
In the Export/Import menu, it is possible to transfer information to and from the control panel
via a USB memory.
The following information can be transferred:
• WELD DATA SETS EXPORT / IMPORT
• SYSTEM SETTING EXPORT / IMPORT
• SETTING LIMITS EXPORT / IMPORT
• MEASURE LIMITS EXPORT / IMPORT
• ERROR LOG EXPORT
• QUALITY FUNCTION LOG EXPORT
• PRODUCTION STATISTICS EXPORT
Carry out the following to save on a USB memory:
Insert the USB memory into the control unit.
Select the row with the information that is to be transferred. Press EXPORT or IMPORT,
depending on whether the information is to be exported or imported.
EXPORT/IMPORT
WELD DATA SETS
SYSTEM SETTINGS
SETTING LIMITS
MEASURE LIMITS
ERROR LOG
QUALITY FUNCTION LOG
PRODUCTION STATISTICS
EXPORT IMPORT QUIT
10.3 File manager
MAIN MENU » TOOLS » FILE MANAGER
In the file manager it is possible to manage information on a USB memory (
C:\
). File
manager makes it possible to delete and copy weld data and quality data manually.
When the USB memory is connected, the display shows the memory's default folder if one is
not previously selected.
The control panel remembers where you were the last time you used file manager, so that
you return to the same place in the file structure when you come back.
