9.3.11 Intermittent welding
INTERMITTENT WELDING
INTERMITTENT WELDING
WELDING LENGTH
TRANSPORT LENGTH
NUMBER OF WELDS

ON
0 mm
0 mm
0
QUIT
To activate the function set intermittent welding to ON. An intermittent welding sequence
consists of weld and transport. At the last weld in a sequence, the transport will not be
performed.
WELDING LENGTH is the length of the weld.
TRANSPORT LENGTH is the length of the transport after a weld has finished.
NUMBER OF WELDS is the number welds to be performed including transport. If the
number of welds is set to “0”, the intermittent welding sequence continues until the user
stops the welding using the red weld stop button.
9.3.12 Polarity (applies only to Aristo® 1000 power source)
In the POLARITY menu you can set the welding polarity.
• To weld with positive polarity on the welding wire and negative polarity on the work
piece, select POSITIVE polarity.
• To weld with negative polarity on the welding wire and positive polarity on the work
piece, select NEGATIVE polarity.
9.3.13 Node id settings (applies only to Aristo® 1000 power source)
If there are I/O nodes in the system the ID numbers are given here.
NODE ID SETTINGS
I/O NODE 1 ID
I/O NODE 2 ID
17
25
QUIT
9.3.14 System information (applies only to Aristo® 1000 power source)
The SYSTEM INFORMATION menu shows active power sources connected via the
CAN2bus, if the power sources are in tandem or parallel mode and if they are configured as
master or slave.
SYSTEM INFORMATION
Active power sources on CAN2
PS id Tandem Parallel
