1.2.2 Unit of measurements
The control panel is set to metric measurement on delivery. To change measurement unit,
proceed as follows:
Press Menu to access the main menu.
Position the cursor on the CONFIGURATION row, using the positioning knob.
SAW
PROCESS
METHOD
REGULATION TYPE
WIRE TYPE
WIRE DIMENSION
CONFIGURATION►
TOOLS►
SAW
DC
CA
Fe SOLID
3.0 mm
SET MEASURE MEMORY FAST MODE
Press ENTER to confirm the selection.
Position the cursor on the GENERAL CONFIGURATION row.
CONFIGURATION
LANGUAGE
CODE LOCK
GENERAL CONFIGURATION►
MACHINE CONFIGURATION►
CABLE LENGTHS►
MAINTENACE►
MEASURE-VALUES FILTER FACTOR
ENGLISH





ONE
QUIT
Press ENTER to confirm the selection.
Position the cursor on the UNIT OF LENGTH row. Press ENTER to bring up a list of the
measurements that are available in the control panel.
