SECTION 7 Replacement Parts
7-23
PT-20 AMX Plasma Torch with Coaxial Pilot Arc Cable
With 4 ft. torch leads, without handle rack P/N 0558002632
With 17 ft. torch leads, without handle rack P/N 0558002633
With 25 ft. torch leads, without handle rack P/N 0558003381
Ref. Description ...................................................................................................
.
Part Number
1 Torch Lead Assembly – 4 ft........................................................................
.
0558002638
Torch Lead Assembly – 17 ft......................................................................
.
0558002639
Torch Lead Assembly – 25 ft......................................................................
.
0558003383
4 Lock Ring......................................................................................................
.
57N70
5 Rubber Boot .................................................................................................
.
0558001157
6 Wrap with electrical tape as shown ..................................................................... Reference
7 H.F. Connector.............................................................................................
.
17974
8 Set screw 6-32 X 3/16 ............................................................................................ Reference
9 Insulate with vinyl tubing and secure with electrical tape ................................ Reference
10 Handle and sleeve without rack .................................................................
.
22329
11 Handle..................................................................................................................... Reference
12 Basic Torch Body Assembly ......................................................................
.
21359
13 O-ring supplied with torch body ................................................................
.
5W92
14 O-ring supplied with torch body ................................................................
.
488157
15 Shield Shroud – 25 ft...................................................................................
.
72020003
16 Lubricant.......................................................................................................
.
17672
