SECTION 2 PCM-875A Mechanized Plasma Cutting System Description
2-3
2.3 Remote Arc Starter (RAS-2)
The remote arc starter (RAS-2) is placed inline
between power console and torch. The RAS is the
source of high frequency energy used to start the
plasma cutting process.
RAS-2 with 15,2 m leads
RAS-2 with 30,4 m leads
P/N 0558003601
P/N 0558003602
Technical Specifications
Input: 110 VAC, 50/60 Hz. Control power provided by
PCM-875A console.
Spark Gap: 1mm
Dimensions and Weight
123,8mm
374mm
184,2mm
Weight = 3,4kg
