SECTION 2 PCM-875A Mechanized Plasma Cutting System Description
2-1
2.1 General
The PCM-875A Mechanized Plasma Cutting
System is a compact 60 ampere package
consisting of plasma power console, remote arc
starter, and PT-20AMX plasma torch. Simple
bulkhead connections allow easy system assembly.
Connect to input power and a source of clean, dry,
compressed air (5,18 to 5,87 bar) and you can
begin cutting up to 13 mm thick material.
2.2 PCM-875A Power Console
There are 2 power console options available:
230 V 50 Hz, 1 or 3 phase P/N 0558003356
400 V 50 Hz, 3 phase P/N 0558003357
2.2.1 Technical Specifications: PCM-875A
230V 50Hz, 3 Phase
P/N 0558003356
Options
1 phase 3 phase
400V 50Hz, 3 phase
P/N 0558003357
60% Duty Cycle 60 A at 120 VDC
Rated Output
100 % Duty Cycle 50 A at 120 VDC
Output Current Range 10 to 60 A/phase
Open Circuit Voltage 275 VDC
Rated Primary Input at 7,2 kW Maximum
Output Power, 60 A at 120 VDC
55/49 A
(230V, 1
phase)
26/24 A per
phase
(230V, 3
phase)
13 A/phase
Power Factor at 60 Amperes Output
74% (230 V,
1 phase)
90% (230 V, 3
phase)
92% (400 V, 3 phase)
Efficiency at 60 Amperes Output 90% typical
Current Capacity 60 A DCSP
Air Requirements 153,4 l/minute at 5,2 bars
Power Cord Length Provided 1,8m 3,1m
