SECTION 4 PCM-875A Mechanized Plasma Cutting System Operation
4-16
Material:
Aluminum
Amperes:
40
PT-20AMX
Plasmarc Torch
Gas:
Air
Lock Ring P/N 57N70
Handle with
Sleeve
P/N
05508003419
Torch Body P/N 21359
Electrode
Holder
Assembly
P/N 21332
Electrode
Insulator
P/N 21373
Electrode
50Hz
P/N
0558001617
Nozzle 50A P/N 21330
Heat Shield –
Blue
P/N 21326
Note: Heat shield rated at 70 to
100A is used for this application
