ST-SM8l Page 35 of 43
SES 2000 AUTOCLAVE Part 4
PART 4 ILLUSTRATED PARTS LIST 2: GENERAL SPARES
Fig. 10 Part No Description Qty.Per Recommended Holding
Item No Standard Long Unit Per Unit Per Year
1 490290 490142 Chassis 1 -
2 490310 490144 Top cover 1 -
3 111928 Screw, self tapping 4 4
4 490063 490146 Dividing panel 1 -
5 490283 Front panel (without printer) 1 Not available for purchase
6 490282 Front panel (with printer) 1 -
7 - Pressure chamber assy. (See Parts List 1)
8 490228 490178 Carrier assembly, tray 1 -
9 - Tray (REF 87-040-07) 4 -
10 490046 Reservoir (requires kit 112472) 1 -
* 425170 . Surface tension breaker
* 425062 . Reservoir lid rectangular (without switch hole)
11 475872 . Reservoir aperture cover (round) 1 -
12 425146 Ring, grey rubber 1 1
* 425165 . Ring, adhesive - -
13 425141 Ring seal, silicone 1 1
14 480301 Foot, c/w fixing screw 4 -
* 380045 Spacer, foot 2 -
15 490302 490304 Door cover assy. 1 -
16 - Door assy. 1 -
17 480315 . Door beam assy. 1 -
18 490076 . Door knob 1 -
19 427011 . Door secondary latch 1 -
20* 427023 . Spring, secondary latch 1 -
21 490017## . Door, pressure assy. 1 -
22 424238## . Seal, retaining rim 1 -
23 427037 . Door seal (gasket) 1 1
24 427015 . Retaining disc, seal 1 -
25 427090 . Seal washer, steel 1 1
26 713651## . O-ring (on older models) 1 1
27# 307232# . Aerotight nut# 1 1
28 427010 Safety catch, door 1 -
29* - Tray lifter (REF 87-040-90) 1 -
30* 301409 Drip tray 1 -
31* 425188 Accessory pack containing 1 -
4 off each, cups and spacers for
cabinet feet
32* REF 87-040-66 Pouch rack accessory A/R -
33 490291 Printer assembly 1 -
34 490397 S.S.R.B.Insulation 1 -
35 424395 Fuse cover 1 -
36 424396 Water shield, control board 1 -
37 427007 Door spindle assembly 1 -
38 427008 Link 1 -
* 380034 Cable saddles A/R -
* 380033 Self mount cable ties A/R -
* 301600 P.T.F.E.Tape A/R -
* 306234 Hydraulic sealant A/R -
* Not illustrated # Now replaced by M6 Nut (710372) and M6 Spring washer (710721)
## For units with an 'O' ring (before c.1999) replace parts 21, 22 and 26 with
parts 21 and 22 only (latest design of these parts eliminates need for 'O' ring).
