Printer Output
The printer output gives the following information:
♦ Manufacturer’s name Eschmann Equipment
♦ Machine type SES 2000
♦ Serial number Nine character code
♦ Cycle type e.g. 134°C no drying
♦ Time and date started At hh:mm:ss
On dd:mm:yy
♦ Counter reading Five digits with leading
zeros
♦ Time/temp information Time every 22 secs
(approx.) + temp. +
graph of temperature.
♦ Cycle ended message
♦ Time and date ended The ‘cycle end’ is
defined as the end of
the sterilizing phase.
If an error occurs during the cycle, it is recorded with
date and time on the printout and the message
‘CYCLE FAILED’. Errors are designated by error
codes as follows:
ERR1 - Faulty temperature sensor/channel
detected
ERR2 - Door open during cycle
ERR3 - Chamber did not fill with water (LoH2O)
ERR4 - Water loss early in cycle (H2O)
ERR5 - No heat
ERR6 - Control temperature low
ERR7 - Control temperature high
ERR8 - Monitor temperature low
ERR9 - Monitor temperature high
These error codes will generally require investigation
by an Eschmann trained engineer.
Front Panel Controls (Fig. A1)
All controls for the printer are on the front of the panel.
a. Door Latch Button - To open door (1) push the
door latch (2) sideways, in the direction of arrow,
and pull the door open to expose paper roll (4).
b. Paper Feed Button - Ensure the sterilizer mains
‘on/off switch is in the ‘I’ (on) position. Press
lower part of paper feed button (3) to activate
paper feed, which will continue for as long as
the button is depressed.
Paper Roll Renewal
CAUTION:
DO NOT USE ALTERNATIVE PAPER ROLLS
The quality and size of paper rolls used in the printer,
can only be supplied by Eschmann Equipment.
Renew paper roll as follows (Fig. A1 and A2):
a. Open autoclave chamber door to provide more
access.
b. Push door latch button (2) sideways, in direction of
arrow and pull door open to expose paper roll (4).
c. If any paper remains in the printer, tear end off
against paper tear bar (8) and carefully withdraw
the remaining paper backwards from the rear
of printer mechanism (5).
d. Compress paper roll spring-loaded retainer
button (6) and withdraw empty paper spool
from spindle.
e. Take new roll of paper, separate paper end
from the roll. Remove any damaged or gummed
part of the paper.
f. Compress paper roll spring-loaded retainer
button (6) and locate new paper roll on spindle
with paper unreeling counter-clockwise as seen
from open end of spindle (Fig. A1).
g. Using scissors, trim end of paper roll at an
angle of approximately 30° (Fig. A4) and insert
this end of the paper into the paper insert slot
(1). Press paper feed actuator arm (7) until
mechanism grips paper and pulls it through to
front of printer door.
h. Turn paper roll by hand to take up any slack paper
i. Close the printer door. Check paper feed by
pressing paper feed button (3) until the end of the
trimmed paper is clear of the tear bar. Ensure that
the paper feeds freely from the printer.
Ribbon Cartridge Renewal (Fig. A3 and A4)
Renew ribbon cartridge as follows:
a. Remove paper roll.
b. Support door with left hand and press upwards with
right hand on bottom of printer mechanism chassis
(Fig. A2-2) and separate chassis from door.
CAUTION:
Do not pull printer mechanism chassis from
door until catch has been released.
c. Leaving printer door fully open, expose printer
mechanism and ribbon cartridge (Fig. A4-1).
d. Pinch the end of ribbon cartridge marked ‘PUSH’
(Fig. A4-1) and remove cartridge.
e. Install new cartridge, checking that left hand side
of cartridge is correctly located on drive shaft,
and CAREFULLY press cartridge into place.
f. Ensure ribbon is taut. If necessary tighten
ribbon by turning faceted disc (Fig. A2-2) on
cartridge, clockwise, using finger or fingernail.
g. Fit paper roll as described above.
