Page 38 of 43 ST-SM8l
Part 4 SES 2000 AUTOCLAVE
Fig. 11 Part No Description Qty.per Recommended Holding
Item No Standard Long Unit Per Unit Per Year
13 110249 Transformer with shroud 1 -
* 110250 . Transformer shroud 1 -
14 301478 Solid state relay (not for CE Units**) 1 -
14A 301481 Relay control board 1 -
15* 696952 Varistor assy. 1 -
16 380012 Terminal block 1 -
17 380001 301890 Fuse holder, large 2 -
18 301814 Fuse holder, small 1 -
19* - Fuse: 2 2
Standard Long
* 380003 301871 F10A 230/ 240V F15A 240V 2 1
* 380002 301871 F13A 220V F15A 220V 2 1
* 111940 F16A 110V 1 1
20* Fuse: 1 1
* 696181 F400mA 220/230/240V 1 1
* 380004 F800mA 110V 1 1
21 490080 Cable, power supply, assy. UK# 1 -
(inc. fused plug) (230V)
22 710894 Clamp, cable 1 -
23 710897 Nut, cable clamp 1 -
24* 427022 Leafspring, microswitch actuator arm1 -
25 427104 Lever assy. microswitch 1 1
26* 427020 Actuator arm, microswitch 1 -
27 490337 Printer interface board 1 -
29 490025 (CE ONLY**) Solenoid door lock 1 -
30 427060 (CE ONLY**) Locking bolt 1 -
31* 380072 (CE ONLY**) Ferrite clamp 3 1
mains loom
32* 380073 (CE Printer version ONLY**) 1 1
Printer ribbon
33* 490342 (CE ONLY**) E.M.I. Shield 1 -
* Not illustrated
** See note below
PART 4 ILLUSTRATED PARTS LIST 3: HEATER AND PROCESS CONTROLS
# For other countries consult manufacturer.
IMPORTANT NOTE: From late 2008 all non-CE units are built as CE units (i.e. all units will be
built to the CE format). Comments qualified by 'non-CE units only' no longer apply and 'CE
only' will apply to all units.
