SES 2000 AUTOCLAVE Part 4
PART 4 ILLUSTRATED PARTS LIST 3: HEATER AND PROCESS CONTROLS
Fig. 11 Part No Description Qty.Per Recommended Holding
Item No Standard Long Unit Per Unit Per Year
1 412012 Heating element 230V, 2kW - -
416220 Heating element 230V, 2.75kW - -
412008 Heating element 110V, 1.4kW - -
2 425114 Thermal fuse assy. 10A 1 1
(220V/240V units)
380081 Thermal fuse assy. 20A 1 1
(110V units)
380081 Thermal fuse assy. 20A 1 1
3 301162 Microswitch 1 1
4* 427021 Stop pin, microswitch 2 -
5 480314 Sensor, water level assy. 1 -
* 301806 . Shouldered washer 1 1
* 301807 . Silicone bush 1 1
* 425124 . Insulation bush 1 1
* 425121 . Water level body 1 1
6 380026 Thermostat assy. 1 -
7* 416149 Clamp, thermostat sensor bulb 1 -
8 427020 Actuator arm, microswitch 1 -
9 490260 Sensor, temperature, assy. 1 1
490260 Sensor, temperature, assy. 2 2
(for units with printer)
9A 490262 Plate, retaining sensor 1 -
10 301127 Lamp, neon, red (overheat) 1 -
11 380000 Power switch, on/off 1 -
12 490335 490338 Controller board assy. 1 -
* 490336 . Daughter board 1 -
* 301797 . Fuse F2A, 20 mm 1 1
* Not illustrated
Continued
