ST-SM8l Page 5 of 43
SES 2000 AUTOCLAVE
Electrical Data
Supply 230Vac at 50/60Hz
Nominal Loading @ 230V - 2.75kW (12A)
Fuses Chassis
15A, 250V, (x2) Part No. 301871
400mA, Part No. 696181
Relay board
T2A, 250V (x1)
Safety standards
IEC1010-1 (1990)
IEC 601-1-2 (1993)
Sterilizing Data
Sterilizing time
At 134/137°C 3 mins 20 sec.
At 121/124°C 15 mins
Typical overall cycle 134°C : 13 minutes
time (D indicates 134°C : 30 minutes (D)
drying included) 121°C : 24 minutes
121°C : 41 minutes (D)
Note: Overall cycle times may vary depending
on machine and loading conditions.
Nominal Operating pressures:
134°C cycle - 3.14 bar abs
121°C cycle - 2.11 bar abs
Water reservoir
capacity 2.0 litres
Dimensions
Autoclave Width 460mm
Length 650mm*
Height 360mm
* Feet spaced to fit 600mm worktop
Chamber Diameter 200mm
Length 500mm (max)
Capacity 15.6 litres
Trays Width 180mm
Length 457mm
Height 24mm
Tray Loading 3.0 kg per tray
Weight (approx.)
Net 35.5kg
Shipping 40kg
Symbols
For use with alternating current
Caution Hot Surface
Caution refer to accompanying
documents
Sterilising cycle without drying phase
(NB. temperature = cycle temperature)
Sterilising cycle with drying phase
(NB. temperature = cycle temperature)
TECHNICAL DATA
(Long Version)
