Essilor Mr Blue 2.0 - Descriptive Diagrams

USER MANUAL > FIRST STEPS WITH MR. BLUE 2.0
Mr Blue 2.0 > v4.0 -09.16 11
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
This chapter contains all the information concerning a first use of the tracer-centerer-blocker:
Tracer (p.11)description
Using the device (p.13)
1. Descriptive diagrams
This section consists of descriptions and the list of accessories of the tracer-centerer-blocker:
Screen
ON/OFF button
Pattern holder
Operating accessory hatch
Centering chamber
Protective glass
Tracing table
Pad dispenser
Posiblock dispensers (on both sides of the screen)
Service accessory hatch
Blocking arm
Indexer
Access to roll of pads
Screen tilt buttons
Manufacturer plate
Connectors
