Estun E-Series User Manual

E300 Operation Manual
Programming
Document Version: V1.01
ESTUN AUTOMATION Proprietary
2-14
Y-axis correction
The range of this parameter is from ﹣99.999 to 99.999.
When the actual axis position is not corresponding with the displayed value, it is possible to correct
the position with this parameter.
It may be repeating to set Corr. Y. However, we can learn from experience, program the process by
the given angle, and measure the depth of 1 degree as the unit length. Then, program the process by
the given depth, and set Corr. Y according to the unit length. Repeat this operation, until the bending
result is corresponding with your requirement.
X-axis correction
The range of this parameter is from ﹣99.999 to 99.999.
When the actual axis position is not corresponding with the displayed value, it is possible to correct
the position with this parameter.
The setting of X-axis correction is same with Angle correction. For example:
 When the programmed and displayed value is 100.00, while the actual axis position value is
102.05, then you shall set the Corr. X to -2.05.
 When the programmed and displayed value is 100.00, while the actual axis position value is
98.05, then you shall set the Corr. X to 1.95.
The machine can stop any time in Single-Step bending, and then
you can modify the programmed value of X-axis, so Corr. X is not
necessary in Single-Step programming.
However, there are a number of bending steps in Multi-Step
programming, and Corr. X is assigned to each step.
2.8 Program Management
2.8.1 Create a Program
Press F5 key to enter the Program page, as shown in Figure 2-8.
