Estun E-Series User Manual

E300 Operation Manual
Outline
Document Version: V1.01
ESTUN AUTOMATION Proprietary
1-5
1.4 Electrical Specifications
Power Supply
Item
Voltage Rated Current Starting Current
Minimum
20 1.2 -
Standard
24 2 -
Maximum
28.8 3 3
Unit
V A A
Inputs
Input Voltage
24VDC±10%
Input Current
5mA
Signal Characteristic
H-level is not greater than 30V
L-level is not greater than 1.2V
Effective Level
H-level
Outputs
Output structure
Open Collector
Output Voltage
Not greater than 30VDC
Output Current
Not greater than 150mA
Signal Characteristic
H-level is not greater than 30V
L-level is not greater than 1.0V
Effective Level
L-level
Encoder
Supported Type
Differential / Line Driver Complementally / Voltage
Supply Voltage
5V DC 12V DC
Supply Current
500mA
Response Frequency
500KHz
Input Phases
A, B, C, A\, B\, C\
Output Phases
A, A\, B, B\, C, C\
A, B, C
Output Voltage
H-level is not less than 80%VCC
L-level is not greater than 0.3V
