l 5.2.2. motor controll 5.2.2. motor control
The main function of a digital decoder is control the motor. All LokSound 5
decoders are universal and can be used with all the models commonly available
DC motors, regardless if ROCO®, Fleischmann®, Brawa®, Mehano®, Bemo®,
LGB, Märklin® or others. Even coreless motors (eg Faulhaber® or Maxon®) can
be connected.
Current motors you can continue to use, provided you replace the stator coils by
a permanent magnet. For more details see chapter 6.8.5.2.
The load regulation of the 6th generation works with an adjustable
high-frequency control between 10 and 50 kHz and assures extremely silent,
smooth motor operation, particularly with coreless motors. Your locos will crawl
super slowly thanks to 12-bit A / D technology. The load control can be easily
adapted to different engine and transmission combinations (see. Chapter 11).
The minimum and maximum speed of 5 LokSound can be adjusted with two
points that can be customized on request with a speed table with 28 entries. By
ESU unique mass simulation no abrupt transitions are visible even when only 14
speed steps. can now also the PWM measurement period and the length of the
blanking interval to be adjusted for "difficult cases".
General Properties of all Decoders
5.2. General Properties of all Decoders
5.2.1. modes
All LokSound decoder 5 are true multi-protocol decoders with automatic
detection of the operating mode "on-the-fly". The decoder analyzes the track
signal and filters each for Him certain out package. Changing from digital to
analogue and back without any problems. This is important in case your shadow
station is still controlled conventionally. Further acknowledge and follow all
LokSound decoders support the relevant brake modes such as ROCO®, Lenz®
or Märklin® and lead-ben are correct.
In particular, the ABC brake sections are suitable for simple chen signal stop.
Sound decoders are aligned with a high degree of compatibility with the
particular system in order to even infrequent applications.
LokSound 5 dominate the DCC protocol with 14, 28 or 128 speed steps and
recognize automatically the correct setting even. Operation with the long 4-digit
addresses is possible as well.
LokSound loading prevail up to 255 addresses and 28 speed steps for
Motorola® operation certain 5 decoder. With a corresponding center such as the
ESU ECoS you can greatly expand as the Motorola® system boundaries.
All LokSound decoders handle 5 in addition rail ComPlus®. In connection with
so-equipped Digitalzent- eral these decoders report automatically to the head
office and transfer all relevant data. Finally, you'll never have to search for the
address of the locomotive and tedious keys function connect!
All LokSound decoders understand the 5 mfx® compatible M4 data format, and
thus sign up Märklin® mfx® central independently on.
