84
function outputs
• Off delay causes after deactivate the function, the output for a while stays on
until the turn-off delay has expired. Both time periods may be set separately from
each other in increments of 0-15 and control CV then, however, the overall my
same written.
description
Value range seconds
duration
Bits within Control
CV
delay 0-15 0 to 6.144 seconds 0-3
off delay
0-15 0 to 6.144 seconds 4-7
The value that must be written into the control-CV, calcu- lated as follows:
OFF delay * 16 + delay Example: For AUX3 the delay to be = 13; Switch off
delay equal to 8, thus has 8 * 16 + 13 = 141 in the control CV 292 are written.
12.5.3. Grade Crossing holding time
You can define the holding time for the global grade crossing functional on as
you like. In this way, "Grade Crossing" even after switching off the function key
for a while active, which allows interesting game effect remains. The value
desired is stored in CV 132 as a multiple of 0.065 seconds. The default value 80
results in 5.2 seconds.
12.5.4. flashing frequency
You can hide also the blink rate of all light effects gobal. All outputs flash at the
same frequency. The desired value is stored in CV 112 as a multiple of
0.065536 seconds (65,536ms). The factory value 30 results in 1.97 seconds.
12.5.5. Automatic shutdown
Each output usually switches off again as soon as the relevant key is turned off.
But sometimes you have to force an output after a certain time is switched off to
prevent damage.
ROCO® digital clutches tolerated eg control no permanent presence. Using the
Auto shutdown you can specify for each output separately, after which time he
will be disabled automatically - regardless of whether the function key is still on.
Write you desired time, which is to be switched on the output, in the
corresponding CV standing according to above table. The unit is 0.4 seconds.
The work of "0" deactivated fourth this function.
12.5.6. Switch-off delay and
For each output, you can define a switch-on and Ausschaltver- delay.
• Delay causes after pressing the function button while the output remains off until
the input is switching time delay expired. Then, the output is turned on.
