21 CV Table sound decoders
On the following pages you will see listed in tabular form all CVs that have sound decoders. Please only change CVs if you are certain about their importance in Wrong
CV settings may cause the sound decoders not responding properly.
CV Surname description range value
1 loco Address of the locomotive 1 - 127 3
2 Start voltage Sets the minimum speed of the locomotive 1-255 3
3 acceleration time Value multiplied by 0.25 is the time from stop to maximum speed 0 - 255 28
4 braking time Value multiplied by 0.25 is the time from maximum speed to stop 0 - 255 21
5 top speed The maximum speed of the locomotive 0-255255
7 version number Internal software version of the decoder - -
8th Manufacturer ID Manufacturer number (ID) of ESU - The write of the value 8 triggers a reset CVs to the
factory settings
151 -
9 Motor PWM frequency Motor PWM frequency multiple of 1000 Hz. 10-50 40
13 Analog mode, F1-F8 State of the functions F1 to F8 in the analog mode. See section 12.7. 0-255 1
14 Analog mode FL, F9-F15 Status of the functions F0, F9 to F15 in analogue mode. See chap. 12.7. 0-63 1
15
16
Decoderlock Decoder Lock function NMRA. For details see
http://www.nmra.org/standards/DCC/WGpublic/0305051/0305051.html
0 - 255 0
17
18
Extended locomotive address Long address of the locomotive. See section 9.2. 128 -
9999
192
19 Composite address
(Consist Address)
Additional address for consist (multiple traction mode). A value of 0 or 128 means: consist
address deactivated 1 - 127 consist address active, normal direction 129 to 255 consist
address reverse direction
0-255 0
21 Consist mode F1-F8 State of the functions F1 to F8 in Consist mode (traction Association) Meaning of bits
as CV. 13
0-255 0
22 Consist Mode FL, F9-F12 Status of the functions F0, F9 to F15 in Conist mode (Traktionsver- band) significance of the
bits as CV fourteenth
0-63 0
