List of all supported CVs
CV Surname description range value
23 adjust Speed Factor to adjust the acceleration time CV 3. Values from 0 to 127 will be added to the CV.
3 If the values are to be subtracted, in addition, bit 7 set (value 128).
0 - 127 0
24 adjust brakes Factor for adjusting 4. values from 0 to 127, the braking time CV will be added to the
CV. 3 If the values are to be subtracted, in addition, bit 7 set (value 128).
27 braking mode permitted braking modes 28
bit function value
0 ABC braking, voltage greater than at the right side 1
1 ABC braking, voltage is greater on left side 2
2 ZIMO HLU brakes active 4
3 Brake on DC, when polarity opposite the direction of travel 8th
4 Brake on DC, when polarity the same as the direction of travel 16
5 Selectrix® braking diode locomotive brakes when polarity
opposite the direction of travel
32
6 Selectrix® braking diode locomotive brakes when polarity the same as the direction of
travel
64
7 Locomotive brakes with a constant braking distance when FS = 0 128
28 RailCom® configuration Settings for RailCom® 131
bit function value
0 Channel 1 released for broadcast address 1
1 Data transmission allowed on the channel 2 2
7 RailCom® Plus automatic Lokanmeldung active 128
