79
12.5. Configuring the function outputs
Each of the function outputs can be switched on first / needs before it can be
used. In addition, each output can be assigned to an effect and can also be
combined with the global logic functions "Grade Crossing", "dimmer" and "fire
box". The effects are divided into lighting effects and special functions.
The behavior of each function output is well defined with 7 CVs per functional
onsausgang as shown in this table:
Please set the index register CV 31 to 16 and CV 32 to 0 before changing
values.
Note that there are outputs for the light front, rear headlight, AUX1 and AUX2
two complete "sets" of Ausgangskonfigura- functions. This allows you to achieve
assignment special effects together with the function key.
function outputsfunction outputs
exit Mode Select CV inputs and Auschalt-
delay
Automatic shut-off brightness
CV
Special Function CV 1 Special
Function CV 2 Special Function CV 3
Light front (config. 1) 259 260 261 262 263 264 258
Rear light (config. 1) 267 268 269 270 271 273 266
AUX1 (config. 1) 275 276 277 278 279 280 274
AUX2 (config. 1) 283 284 285 286 287 288 282
AUX3 291 292 293 294 295 296 290
AUX4 299 300 301 302 303 304 298
AUX5 307 308 309 310 311 312 306
AUX6 315 316 317 318 319 320 314
AUX7 323 324 325 326 327 328 322
AUX8 331 332 333 334 335 336 330
AUX9 339 340 341 342 343 344 338
AUX10 347 348 349 350 351 352 346
AUX11 355 356 357 358 359 360 354
AUX12 363 364 365 366 367 368 362
AUX13 371 372 373 374 375 376 370
AUX14 379 380 381 382 383 384 378
AUX15 387 388 389 390 391 392 386
AUX16 395 396 397 398 399 400 394
AUX17 403 404 405 406 407 408 402
AUX18 411 412 413 414 415 416 410
Light front (config. 2) 419 420 421 422 423 424 418
Rear light (config. 2) 427 428 429 430 431 432 426
AUX1 (config. 2) 435 436 437 438 439 440 434
AUX2 (config. 2) 443 444 445 446 447 448 442
